AJA openGear 3G-SDI to 3G-SDI/HDMI Scan Converter OG-ROI-SDI DVT

Description
Specifications
0 Reviews

AJA openGear 3G-SDI to 3G-SDI/HDMI Scan Converter. The AJA openGear 3G-SDI to 3G-SDI/HDMI Scan Converter is designed to provide high-quality scan conversion of 3G-SDI inputs to 3G-SDI and HDMI baseband video, allowing you to efficiently incorporate 3G-SDI sources into SDI and HDMI feeds. It also allows region of interest (ROI) image scaling, aspect ratio and frame rate conversion, and up, down, and cross conversion.

The card is compatible with DFR-8321, OG3, and OGX openGear frames. It features a 3G-SDI input and loop output, and 3G-SDI and HDMI 1.4 outputs, all supporting up to 1080p60 resolution.Image H/V flip and 90° rotation.2-channel analog audio output of disembedded audio (two 3-pin terminal block connectors).Sync reference selection (external, openGear frame, or free run).Remote control over Ethernet using Ross DashBoard network control software on Windows, macOS, or Linux.Hot-swappable form factor.Eliminate extra interface clutter and menu bars and extract only the portion of the computer screen you want.

Convert 3G-SDI Input to 3G-SDI and HDMI
Up to 1080p Input and Output
SDI Loop Output; 2 x 3-Pin Audio Outputs
ROI Image Scaling
Aspect Ratio & Frame Rate Conversion
Up, Down & Cross Conversion
Ethernet Control via Ross DashBoard
1080p/1080i/720p Tri-Level Sync
For DFR-8321, OG3 & OGX openGear Frames

AJA openGear 3G-SDI to 3G-SDI/HDMI Scan Converter

The AJA openGear 3G-SDI to 3G-SDI/HDMI Scan Converter is designed to provide high-quality scan conversion of 3G-SDI inputs to 3G-SDI and HDMI baseband video, allowing you to efficiently incorporate 3G-SDI sources into SDI and HDMI feeds. It also allows region of interest (ROI) image scaling, aspect ratio and frame rate conversion, and up, down, and cross conversion. The card is compatible with DFR-8321, OG3, and OGX openGear frames. It features a 3G-SDI input and loop output, and 3G-SDI and HDMI 1.4 outputs, all supporting up to 1080p60 resolution.

Image H/V flip and 90° rotation.
2-channel analog audio output of disembedded audio (two 3-pin terminal block connectors).
Sync reference selection (external, openGear frame, or free run).
Remote control over Ethernet using Ross DashBoard network control software on Windows, macOS, or Linux.
Hot-swappable form factor.
Eliminate extra interface clutter and menu bars and extract only the portion of the computer screen you want. The converter is fully compatible with the free Ross DashBoard application, offering interactive selection of an ROI from the incoming computer signal. You have full control over how that region is scaled to the output resolution using AJA's high-quality scaling algorithms for the cleanest picture quality possible. Take full control of aspect ratio, image rotation, and frame rate conversion with on-screen controls in the DashBoard software that shows you what your source and output will look like, including the formats that are coming in and the choices you have made for the signal going out.
It is also possible to expand output options and create a large, synchronized video wall display.
You're able to easily create highly effective and engaging displays by using additional converters. By utilizing three OG-ROI-SDI openGear converters in the appropriate rack frame, you can feed three display monitors side by side, each rotated to portrait mode. By using the SDI pass-through of the OG-ROI-SDI, the SDI routed image is in sync, with each converter providing the necessary region of interest output via SDI. Settings for each of the converters are provided via Ethernet control via your openGear frame through an Ethernet switch. The result is a visually exciting and creative way to feed display content.
The openGear standard ensures that AJA cards will be compatible with other openGear products from certified openGear partners.
Full and SMPTE.
Free run and Ext Ref.
1080p/1080i/720p tri-level sync, 75-ohm terminating.
openGear standard form factor. Two slots required for each card (front and rear slots).

Video Inputs	1 x BNC (3G-SDI)
Audio Inputs	None
Video Outputs	1 x BNC (3G-SDI) 1 x BNC (3G-SDI) (Loop Output) 1 x HDMI (HDMI 1.4)
Audio Outputs	2 x Block 3-Pin Stereo Analog
Expansion Slots	None
Input Video Format	SDI 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i 50/59.94 fps 720p 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps
Output Video Format	SDI 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps
Embedded Audio	SDI: 16-Channel HDMI: 8-Channel
Video Standard Compliance	SMPTE 259M/292M/424M
HDR Compatibility	None
Wi-Fi	None
Power Consumption	7 W
Operating Temperature	32 to 104°F / 0 to 40°C
Storage Temperature	-40 to 140°F / -40 to 60°C
Operating Humidity	10 to 90%
Weight	0.5 lb / 0.2 kg
Package Weight	0.54Kg
Box Dimensions (LxWxH)	40.89cm x 20.07cm x 8.38cm

In The Box

1 x AJA openGear 3G-SDI to 3G-SDI/HDMI Scan Converter
1 x Limited 5-Year Warranty
