AJA ColorBox HDR/SDR Color Converter. Built for broadcast applications, the AJA ColorBox HDR/SDR Color Converter is an SDR/HDR/WCG signal-supporting device capable of managing color-driven workflows for consistent conversion across live programs. One 12G-SDI input delivers up to UHD 4K video to two 12G-SDI outputs or one HDMI 2.0 output for high-quality video.

The ColorBox can also support up to 16-bit TIFF images. Outfitted with 3D LUT processing with support for 1D LUTs and 3x3 matrices, the ColorBox offers user-configurable color control using industry-standard file types.Five processing pipeline modes, including two licensable upgrade options, are available for the ColorBox: AJA Color, Colorfront, NBCU LUTs, ORION-CONVERT, and BBC HLG LUT.

Converter for Color Management
1 x 12G-SDI Input, 2 x 12G-SDI Outputs
1 x HDMI 2.0 Output
Supports UHD 4K and 16-Bit TIFF
3D LUT Processor
Various Processing Pipeline Modes
Licensable Upgrade Options
Configure via Web Interface
1 x Mini-USB Port, 1 x Gigabit Ethernet
AC Power Adapter Included

AJA ColorBox HDR/SDR Color Converter

Built for broadcast applications, the AJA ColorBox HDR/SDR Color Converter is an SDR/HDR/WCG signal-supporting device capable of managing color-driven workflows for consistent conversion across live programs. One 12G-SDI input delivers up to UHD 4K video to two 12G-SDI outputs or one HDMI 2.0 output for high-quality video. The ColorBox can also support up to 16-bit TIFF images. Outfitted with 3D LUT processing with support for 1D LUTs and 3x3 matrices, the ColorBox offers user-configurable color control using industry-standard file types.

Five processing pipeline modes, including two licensable upgrade options, are available for the ColorBox: AJA Color, Colorfront, NBCU LUTs, ORION-CONVERT, and BBC HLG LUT. Advanced setting control for the device can be achieved via the web user interface using the Gigabit Ethernet port. A mini-USB port on the front panel can connect a third-party controller and configure the initial IP address of the device. Included with the ColorBox is an AC power adapter for integration into your preexisting broadcast configuration.

Ultralow latency, less than half a video line
Seven LUT nodes plus overlay: one 3D LUT processor, four 1D LUT processors, two 3x3 matric processors
Supports industry-standard file types; no conversion is needed
Five color processing pipelines: AJA color, Colorfront mode, NBCU LUTs, ORION-CONVERT mode (Licensed Upgrade), BBC HLG LUT mode (Licensed Upgrade)
Video preview in web user interface for monitoring
Nine built-in test patterns up to UHD 4K
User text, input/output signal, and pipeline configuration in overlay output
Onboard library for file management of 16 1D LUTs, 16 3D LUTs, 16 3x3 matrices, and 16 images
Embedded SDI 16-channel and HDMI 8-channel pass-through
Lightweight 1 RU unit with ultraquiet fan operation
4-pin mini-XLR DC power connector
Select button on the front panel bypasses video processing
Extensive API for third-party control integration
Gigabit Ethernet port and embedded web server for remote control
Configure IP address via mini-USB port and set up software for both Windows and macOS

Colorimetry	BT.709 BT.2020
Video Formats	DCI 4K UHD 4K DCI 2K 1080p 1080i 720p
Video Input	1 x BNC 12G-SDI
SDI Formats Supported	12G-SDI: DCI 4K up to 60, UHD 4K up to 60 6G-SDI: DCI 4K up to 30, UHD 4K up to 60 3G-SDI (Level A or B Dual-Link): DCI 2K up to 5, 2KPsF up to 25, 1080p up to 60, 1080PsF up to 30, 1080i up to 60, 720p up to 60 1.5G-SDI: DCI 2K up to 30, 2KPsF up to 25, 1080p up to 30, 1080PsF up to 30, 1080i up to 60, 720p up to 60
Video Outputs	2 x BNC 12G-SDI 1 x HDMI 2.0 Type A
HDMI Format Support	UHD 4K 2K 1920 x 1080
Color Sampling	YCC 4:4:4/4:2:2, RGB 4:4:4 10/12-Bit (SDI) YCC 4:2:2, RGB 4:4:4 8/10/12-Bit (HDMI)
Latency	< 0.5 Line
Supported Image Formats	TIFF, PNG, JPEG
Audio Input	Embedded SDI 12-Bit, 16-Channel
Audio Output	Embedded SDI 24-Bit, 16-Channel Embedded HDMI 24-Bit, 8-Channel
Network Interface	1 x RJ45 10/100/1000 Ethernet
USB Interface	1 x Mini-USB IP
Power Input	1 x 4-Pin Mini-XLR, 10 to 12 VDC
AC Adapter	100 to 2400 VAC, 50/60 Hz, 60W
Operating Temperature	32 to 122°F / 0 to 50°C
Storage Temperature	-40 to 140°F / -40 to 60°C
Operating Humidity	10 to 90% (Non-Condensing)
Operating Altitude	< 10,000' / < 3,000 m
Dimensions	7.54 x 4.1 x 1.66" / 191.6 x 104.1 x 42.1 mm
Weight	1 lb / 0.5 kg
Package Weight	1.31Kg
Box Dimensions (LxWxH)	26.67cm x 25.65cm x 9.91cm

In The Box

1 x AJA ColorBox HDR/SDR Color Converter
1 x AC Power Adapter
1 x Limited 3-Year Warranty
