Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
SKU:
G1
Availability:
Enquire for ETA
Write a Review
Kiloview
Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
The HD/3G-SDI to RTSP Wi-Fi Video Encoder from Kiloview is a HD/3G-SDI H.264 video encoder that supports HD-SDI/3G-SDI standard compatible signal input, and HD/3G-SDI looping. It has a built-in dual-band (2.4G/5G) Wi-Fi and supports a 10/100M self-adaptive Ethernet interface. This encoder supports unbind audio from HD/3G-SDI signal as well as input audio from analog line-in.
It features a microSD/TF card slot and USB Type-A and mini-USB ports for storage. Multi-language is supported for worldwide users.
- Built-In IEEE 802.11 a/b/g/n Wi-Fi
- HD/3G-SDI Input/Output
- 3.5mm Analog Audio Input & Output
- RJ45 Ethernet Port
- Micro SD/TF Card Slot
- USB Type-A & Mini-USB Ports for Storage
- Two Wi-Fi Antennas
- 12 VDC Power Adapter
- ONVIF Compliant
Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
The HD/3G-SDI to RTSP Wi-Fi Video Encoder from Kiloview is a HD/3G-SDI H.264 video encoder that supports HD-SDI/3G-SDI standard compatible signal input, and HD/3G-SDI looping. It has a built-in dual-band (2.4G/5G) Wi-Fi and supports a 10/100M self-adaptive Ethernet interface. This encoder supports unbind audio from HD/3G-SDI signal as well as input audio from analog line-in. It features a microSD/TF card slot and USB Type-A and mini-USB ports for storage. Multi-language is supported for worldwide users. Two Wi-Fi dual-band antennas and a 12 VDC power adapter are included.
Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
The HD/3G-SDI to RTSP Wi-Fi Video Encoder from Kiloview is a HD/3G-SDI H.264 video encoder that supports HD-SDI/3G-SDI standard compatible signal input, and HD/3G-SDI looping. It has a built-in dual-band (2.4G/5G) Wi-Fi and supports a 10/100M self-adaptive Ethernet interface. This encoder supports unbind audio from HD/3G-SDI signal as well as input audio from analog line-in. It features a microSD/TF card slot and USB Type-A and mini-USB ports for storage. Multi-language is supported for worldwide users. Two Wi-Fi dual-band antennas and a 12 VDC power adapter are included.
- Integrates FPGA, video co-processor and video encoding chip
- Supports 1080p60 Full HD video encoding, meanwhile enabling up to 960x540 at 60 Hz sub-stream encoding
- VLB (Very-Low Bit Rate) H.264 video encoding technology
- Built-in Wi-Fi, supporting USB extension and select network accesses
- Supports multi 4G-LTE dongle bonding communication (available separately)
- Built-in Sunshine streaming media engine, fully supports RTP, RTSP, RTMP, HLS, and TS
- 20-50 concurrent users can access simultaneously
- Supports ONVIF 1.1/2.0 that can be easily connected to secure safety system/NVR system
- Use Web interface to manage device
- Designed for broadcast and TV, interactive media, medical, network education, secure safety, and other fields
- YouTube, UStream, and Twitch global live video platforms supported (tested)
- Wowza, FMS, RED5, and SRS streaming media server platforms/CDN systems supported (tested)
- Supports image rotation, cutting, gray scale, and other special image processing
- Supports character/image overlay
- Supports quick function customization based on customers' needs (Please contact factory technical support)
- Two-way voice intercom function
| Video Input Connectors | 1 x BNC (SD-SDI) |
| Input Video Format | SDI 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps 1080i: 50/59.94/60 fps 720p: 23.98/24/25/29.97/30/50/59.94/60 fps |
| Audio Input Connectors | 1 x 1/8" / 3.5 mm TRS Stereo Analog |
| Embedded Audio Input | SDI |
| Video Output Connectors | 1 x BNC (SD-SDI) (Loop Output) |
| Output Video Format | SDI / RJ45 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps 1080i: 50/59.94/60 fps 720p: 23.98/24/25/29.97/30/50/59.94/60 fps |
| Audio Output Connectors | 1 x 1/8" / 3.5 mm TRS Stereo Analog |
| Embedded Audio Output | SDI |
| Latency | SDI: 67 ms |
| Other I/O | 1 x USB Type-A 1 x USB Mini-B 1 x RJ45 LAN Output |
| Video IP Encoding | H.264: 1920 x 1080 at 60p |
| Audio IP Encoding | AAC, G.711 |
| Memory Card Slots | 1 x microSD (Unspecified Type) |
| Wi-Fi Support | Wi-Fi 4 (802.11n), 802.11a/b/g |
| Power Connector | 1 x Barrel (12 VDC at 1 A) Input |
| Power Consumption | 4 W |
| Operating Temperature | -4 to 176°F / -20 to 80°C |
| Operating Humidity | 20 to 90% |
| Dimensions | 4.92 x 3.5 x 1.1" / 125 x 89 x 28 mm |
| Weight | 13.4 oz / 380 g |
| Package Weight | 0.60Kg |
| Box Dimensions (LxWxH) | 20.83cm x 15.75cm x 8.38cm |
In The Box
- 1 x Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
- 2 x 5 dB 2.4G/5G Dual-Band Antennas
- 1 x 12 VDC Adapter
- 1 x Limited 1-Year Warranty
Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
The HD/3G-SDI to RTSP Wi-Fi Video Encoder from Kiloview is a HD/3G-SDI H.264 video encoder that supports HD-SDI/3G-SDI standard compatible signal input, and HD/3G-SDI looping. It has a built-in dual-band (2.4G/5G) Wi-Fi and supports a 10/100M self-adaptive Ethernet interface. This encoder supports unbind audio from HD/3G-SDI signal as well as input audio from analog line-in. It features a microSD/TF card slot and USB Type-A and mini-USB ports for storage. Multi-language is supported for worldwide users. Two Wi-Fi dual-band antennas and a 12 VDC power adapter are included.
Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
The HD/3G-SDI to RTSP Wi-Fi Video Encoder from Kiloview is a HD/3G-SDI H.264 video encoder that supports HD-SDI/3G-SDI standard compatible signal input, and HD/3G-SDI looping. It has a built-in dual-band (2.4G/5G) Wi-Fi and supports a 10/100M self-adaptive Ethernet interface. This encoder supports unbind audio from HD/3G-SDI signal as well as input audio from analog line-in. It features a microSD/TF card slot and USB Type-A and mini-USB ports for storage. Multi-language is supported for worldwide users. Two Wi-Fi dual-band antennas and a 12 VDC power adapter are included.
- Integrates FPGA, video co-processor and video encoding chip
- Supports 1080p60 Full HD video encoding, meanwhile enabling up to 960x540 at 60 Hz sub-stream encoding
- VLB (Very-Low Bit Rate) H.264 video encoding technology
- Built-in Wi-Fi, supporting USB extension and select network accesses
- Supports multi 4G-LTE dongle bonding communication (available separately)
- Built-in Sunshine streaming media engine, fully supports RTP, RTSP, RTMP, HLS, and TS
- 20-50 concurrent users can access simultaneously
- Supports ONVIF 1.1/2.0 that can be easily connected to secure safety system/NVR system
- Use Web interface to manage device
- Designed for broadcast and TV, interactive media, medical, network education, secure safety, and other fields
- YouTube, UStream, and Twitch global live video platforms supported (tested)
- Wowza, FMS, RED5, and SRS streaming media server platforms/CDN systems supported (tested)
- Supports image rotation, cutting, gray scale, and other special image processing
- Supports character/image overlay
- Supports quick function customization based on customers' needs (Please contact factory technical support)
- Two-way voice intercom function
| Video Input Connectors | 1 x BNC (SD-SDI) |
| Input Video Format | SDI 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps 1080i: 50/59.94/60 fps 720p: 23.98/24/25/29.97/30/50/59.94/60 fps |
| Audio Input Connectors | 1 x 1/8" / 3.5 mm TRS Stereo Analog |
| Embedded Audio Input | SDI |
| Video Output Connectors | 1 x BNC (SD-SDI) (Loop Output) |
| Output Video Format | SDI / RJ45 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps 1080i: 50/59.94/60 fps 720p: 23.98/24/25/29.97/30/50/59.94/60 fps |
| Audio Output Connectors | 1 x 1/8" / 3.5 mm TRS Stereo Analog |
| Embedded Audio Output | SDI |
| Latency | SDI: 67 ms |
| Other I/O | 1 x USB Type-A 1 x USB Mini-B 1 x RJ45 LAN Output |
| Video IP Encoding | H.264: 1920 x 1080 at 60p |
| Audio IP Encoding | AAC, G.711 |
| Memory Card Slots | 1 x microSD (Unspecified Type) |
| Wi-Fi Support | Wi-Fi 4 (802.11n), 802.11a/b/g |
| Power Connector | 1 x Barrel (12 VDC at 1 A) Input |
| Power Consumption | 4 W |
| Operating Temperature | -4 to 176°F / -20 to 80°C |
| Operating Humidity | 20 to 90% |
| Dimensions | 4.92 x 3.5 x 1.1" / 125 x 89 x 28 mm |
| Weight | 13.4 oz / 380 g |
| Package Weight | 0.60Kg |
| Box Dimensions (LxWxH) | 20.83cm x 15.75cm x 8.38cm |
In The Box
- 1 x Kiloview HD/3G-SDI to RTSP Wi-Fi Video Encoder
- 2 x 5 dB 2.4G/5G Dual-Band Antennas
- 1 x 12 VDC Adapter
- 1 x Limited 1-Year Warranty
